This post was semi automatically converted from blogdown to Quarto and may contain errors. The original can be found in the archive.
There are many network repositories out there that offer a large variety of amazing free data. (See the awesome network analysis list on github for an overview.) The problem is, that network data can come in many formats. Either in plain text as edgelist or adjacency matrix, or in a dedicated network file format from which there are many (paj,dl,gexf,graphml,net,gml,…). The package igraph
has an import function for these formats (read_graph()
) but I have found it to be unreliable at times.
The networkdata
package collates datasets from many different sources and makes the networks readily available in R. The data is very diverse, ranging from traditional social networks to animal, covert, and movie networks. In total, the package includes 979 datasets containing 2135 networks. As such, I hope this package to be a good resource for teaching, workshops and for research if example data is needed. You can only get so far with the Karate network.
library(igraph)
library(networkdata)
Install
Due to the nature of the package (only data, no functions), it will not go to CRAN at any point. However, the package is available via drat (If you are looking for stable builds of the package). With drat, you can install and upgrade non-CRAN packages directly from R using the standard install.packages()
and update.packages()
functions.
# install.packages("drat")
::addRepo("schochastics")
dratinstall.packages("networkdata")
To save on line of code in the future, you can add drat::addRepo("schochastics")
to your .Rprofile
.
The developer version is available via github.
::install_github("schochastics/networkdata") remotes
The required space for the package is ~22MB, given that it includes a lot of data.
Overview
So far, the package includes datsets from the following repositories:
- Freeman’s datasets from http://moreno.ss.uci.edu/data including most of the classical (small) datasets in social network analysis.
- The movie networks from https://dataverse.harvard.edu/dataset.xhtml?persistentId=doi:10.7910/DVN/T4HBA3 includes interactions among characters in 773 movies which were automatically parsed from scripts.
- Covert networks from https://sites.google.com/site/ucinetsoftware/datasets/covert-networks. Around 50 datasets of networks with different criminal activities (drugs, terrorism, etc.). This dataset was originally compiled by the Mitchell Centre for SNA.
- Animal networks from https://bansallab.github.io/asnr/. A large collection of networks with different interactions (dominance, grooming, etc.) in groups of different species.
- Shakespeare’s plays networks build with data from https://github.com/mallaham/Shakespeare-Plays. Similar to the movie dataset. Includes scene co-appearances of characters in 36 plays of Shakespeare.
- Some networks from http://konect.uni-koblenz.de/. Konect is a large repository of network data. Only a view small datasets are included from there.
- Tennis networks compiled from https://github.com/JeffSackmann (please give credit to him if you use this data). Includes all matches between 1968 and 2019 (both WTA and ATP) as yearly networks. The networks are directed, pointing from loser to winner with the surface (hard, grass, etc) as edge attribute.
- Some random datasets I had lying around (e.g. the “Grey’s Anatomy” hook-up network)
All networks are in igraph
format. If you are used to work with the network
format (as in sna
and ergm
), you can use the intergraph package to easily switch between igraph
and network
.
A list of all datasets can be obtained with
data(package = "networkdata")
Alternatively, use the function show_networks()
to get a list of datasets with desired properties.
head(show_networks(type = "directed"),n = 10)
## variable_name network_name is_collection no_of_networks
## 38 ants_1 ants_1 FALSE 1
## 39 ants_2 ants_2 FALSE 1
## 42 atp atp TRUE 52
## 45 bkfrac bkfrac FALSE 1
## 47 bkoffc bkoffc FALSE 1
## 49 bktecc bktecc FALSE 1
## 50 bott bott FALSE 1
## 55 cent_lit cent_lit FALSE 1
## 106 dnc_temporalGraph dnc_temporalGraph FALSE 1
## 109 eies_messages eies_messages FALSE 1
## nodes edges is_directed is_weighted is_bipartite has_vattr
## 38 16.0000 200.000 TRUE FALSE FALSE FALSE
## 39 13.0000 361.000 TRUE FALSE FALSE FALSE
## 42 499.3462 3164.404 TRUE TRUE FALSE TRUE
## 45 58.0000 3306.000 TRUE TRUE FALSE FALSE
## 47 40.0000 1558.000 TRUE TRUE FALSE FALSE
## 49 34.0000 1122.000 TRUE TRUE FALSE FALSE
## 50 11.0000 256.000 TRUE TRUE FALSE TRUE
## 55 129.0000 613.000 TRUE FALSE FALSE FALSE
## 106 1891.0000 37421.000 TRUE FALSE FALSE FALSE
## 109 32.0000 460.000 TRUE TRUE FALSE TRUE
If you use any of the included datasets, please make sure to cite the appropriate orginal source, which can be found in the help file for each network.
